PUV-1510RXWP 5-Play HDBaseT™ Wall Plate Receiver (inc. PoH & single LAN, up to 100m)
The PUV-1510RXWP Receiver will accept transmitted video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-232, PoH (Power over HDBaseT), and LAN signals up to 100m. This solution provides advanced signal management ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are received simultaneously over a single CAT6a/7 cable up to 100m. Wall plate version designed for a UK 2-gang back box.
Technical Specifications:-
•HDCP 2.2 & 1.x Compliant
•Supports uncompressed video/audio up to 10.2Gbps
•Supports HDCP repeating and CEC bypass
•Supports resolutions VGA~WUXGA, 480i~1080p, 4K UHD @ 24/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K UHD @ 60Hz (YUV 4:2:0), 4K/2K @ 24/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/2K @ 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings
•4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7
•1080p signals can be transmitted up to 100m via CAT5e/6/6a/7
•Supports all common digital audio formats
•5-Play™ convergence: HDMI, LAN, PoH & Control (IR & RS232)
•2-gang UK back box Wall plate version
Inputs 1x RJ45 [1x HDBaseT HDMI & Propriety Data]
1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
1x RJ45 [1x LAN Serving]
Outputs 1x HDMI [1x HDMI Uncompressed AV and Data]
1x 3.5mm Stereo mini-jack [1x Infra Red Emitter]
1x 9pin Dsub [1x RS-232 Data]
POE PSU: PoH
Dimensions 90mm [W] x 156mm [D] x 42mm [H]
Net Weight 290g
Gross Weight 600g
