Martin Logan
Martin Logan Balanced Force 212 Subwoofer
£4,995.00 inc. VAT
(£4,162.50 ex. VAT)
Available - 2-3 Days
System Frequency Response
18–120 Hz ±3dB; Anechoic through LFE effects input
Low Pass Filter Frequencies 30 - 80Hz
Phase 0°, 90°, 180°, 270°
° 25Hz Level Control ±10dB at 25Hz
Power Control On, Auto (12V Trigger), Off
Room Correction Perfect Bass Kit (PBK) Ready (Sold Separately)
Woofers Two 12" (30.5cm) cast-basket, highexcursion, aluminum cone with extended throw driver assembly, sealed non-resonant asymmetrical chamber format
Amplifiers 2 x 850 watts (3,400 watts peak system total)
Inputs RCA: Left, Right and LFE. XLR: Left, Right and LFE. Speaker Level: Left and Right banana jacks. 12V Trigger: 3.5mm Mini USB (for PBK) USB (for crossover & firmware updates)
Output (RCA) Multi Out (for multi-sub connection)
Input Impedance RCA: 10,000 Ohms XLR: 15,000 Ohms per phase Speaker Level: 10,000 Ohms per phase (20,000 Ohms red to black)
Power Draw Typical: 250 Watts Idle: 30 Watts
Weight 140lbs. (63.5kg) each
Overall Dimensions (HxWxD) 22.6 x 22.6 x 22.9 (57.4cm x 57.4cm x 58.2cm)
Low Pass Filter Frequencies 30 - 80Hz
Phase 0°, 90°, 180°, 270°
° 25Hz Level Control ±10dB at 25Hz
Power Control On, Auto (12V Trigger), Off
Room Correction Perfect Bass Kit (PBK) Ready (Sold Separately)
Woofers Two 12" (30.5cm) cast-basket, highexcursion, aluminum cone with extended throw driver assembly, sealed non-resonant asymmetrical chamber format
Amplifiers 2 x 850 watts (3,400 watts peak system total)
Inputs RCA: Left, Right and LFE. XLR: Left, Right and LFE. Speaker Level: Left and Right banana jacks. 12V Trigger: 3.5mm Mini USB (for PBK) USB (for crossover & firmware updates)
Output (RCA) Multi Out (for multi-sub connection)
Input Impedance RCA: 10,000 Ohms XLR: 15,000 Ohms per phase Speaker Level: 10,000 Ohms per phase (20,000 Ohms red to black)
Power Draw Typical: 250 Watts Idle: 30 Watts
Weight 140lbs. (63.5kg) each
Overall Dimensions (HxWxD) 22.6 x 22.6 x 22.9 (57.4cm x 57.4cm x 58.2cm)
£4,162.50
